TSB23003DS by te connectivity / buchanan brand
Image is representational - see mfr. specs

TSB23003DS

TE Connectivity / Buchanan Brand

Conn Europa Terminal Blocks 6 POS 8mm Screw Cable Mount 30A/Contact ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

TSB23003DS is a Europa series terminal block designed for secure electrical connections in various applications. It features 3 circuits with an 8.00 mm centerline spacing and accommodates wire sizes ranging from 0.12 to 3.00 mm² (26-12 AWG). The terminal block is rated for 30 A current and 250 VAC voltage, with a temperature range up to 105°C. Constructed with a polyamide housing, brass contacts with tin plating, and stainless steel wire protector, it offers reliable performance and durability. This RoHS compliant component is UL recognized (File No. E63810) and CSA certified (File No. LR28387), making it suitable for industrial control panels, power distribution, and general-purpose wiring applications.

Product Highlights:

  • Terminal Block
  • 8.00 mm Centerline
  • Number of Circuits = 3
  • Wire Range = 0.12-3.00; [26-12] mm [AWG]
  • With Wire Protection

Search Keywords: TSB23003DS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Buchanan Brand
Part No:
TSB23003DS
Alias/AKA:
1776293-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
Europa Terminal Blocks
Mounting:
Cable Mount
Gender:
N/A
Termination Method:
Screw
Pitch:
8 mm
Number of Circuits:
3
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
30/Contact A
Wire Size:
12-26 AWG
Operating Temperature:
105(Max) °C

IN STOCK: 853

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
25
$1.589
250
$1.303
500
$1.216
1,000
$1.155
2,500
$1.148
5,000
$1.045
7,500
$0.934
10,000 +
$0.930
