3224W-1-503E by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

3224W-1-503E

Trimmer Potentiometer - 50K Ohm - 0.25W(1/4W) - 12(Elec)Turns - 4.8 X 3.9 X 5.3mm - J-Hook - Surface Mount. ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The Trimpot 3224 series from Bourns are cermet, surface mount trimming potentiometers. These potentiometers are multiturn which performs a variety of circuit adjustments in all types of electronic equipment. Typical applications are measuring linear distance, angle or rotation in production equipment. The pick and place centering design have flush adjustment. The design meets EIA/EIAJ/IPC/VRIC SMD standard trimmer footprint. Wiper idles when the stop is reached. Operating temperature ranges from -65°C to +150°C.

Search Keywords: 3224W1503E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3224W-1-503E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
REEL
Mounting:
Surface Mount
Number of Turns:
12(Elec) Turns
Termination Style:
J-Hook
Power Rating:
0.25 (1/4) W
Resistance Value:
50 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
4.8 x 3.9 x 5.3 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 38,250

Can Ship immediately

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
250
$2.24
500
$2.15
1,000
$2.09
2,500
$2.01
5,000
$2.00
7,500
$1.99
10,000 +
$1.98
Reel Package
Log in for special pricing Click for Quote Price Match Request
