3296W-1-100LF by bourns
Image is representational - see mfr. specs

3296W-1-100LF

Bourns

Res Cermet Trimmer 10 Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (9.53 X 4.83 X 11.55mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BOURNS part 3296W-1-100LF is a high-quality Res Cermet Trimmer with a resistance of 10 Ohms and a tolerance of 10%. It has a power rating of 0.5W (1/2W) and operates with 25 (Elec) turns. The compact size of 2.19mm (9.53 x 4.83 x 11.55mm) makes it suitable for various applications. This trimmer is designed for pin Thru-Hole mounting and is conveniently packaged in a tube for easy handling and storage. It is a reliable and versatile component ideal for precise adjustments and calibration in electronic circuits.

Search Keywords: 3296W1100LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3296W-1-100LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
10 Ohm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
9.53 x 4.83 x 11.55 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 300

Ships today, if you order in

On Order: 1,000   can ship 7/20/26

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
100
$1.373
300
$1.278
500
$1.246
1,000
$1.216
2,500
$1.210
5,000
$1.075
7,500
$1.070
10,000 +
$1.064
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
