3296Z-1-205LF by bourns
Image is representational - see mfr. specs

3296Z-1-205LF

Bourns

Res Cermet Trimmer 2M Ohm 10% 0.5W(1/2W) 25(Elec)Turn 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3296Z-1-205LF is a 3/8" square Trimpot trimming potentiometer manufactured by Bourns, designed for precision resistance adjustment in industrial applications. This multiturn cermet device features a 2 megohm resistance value with ±10% tolerance, infinite resolution, and a sealed chevron design for environmental protection. It offers exceptional adjustability with voltage accuracy of ±0.01% and resistance accuracy of ±0.05%, along with an effective travel of 25 turns nominal. The potentiometer operates across a wide temperature range of -55°C to +125°C with a temperature coefficient of ±100 ppm/°C, and is rated for 0.5 watt at 70°C. Its RoHS-compliant termination (100% tin-plated) and solderable pins make it suitable for automated assembly in instrumentation, data acquisition, and precision control circuits where reliable, repeatable adjustment is essential.

Search Keywords: 3296Z1205LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3296Z-1-205LF
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536308000
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
25(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
2 MOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
11.05 x 4.83 x 10.03 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 646

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
100
$1.467
300
$1.288
500
$1.284
1,000
$1.056
2,500
$0.990
5,000
$0.965
7,500
$0.942
10,000 +
$0.940
