BD06 by littelfuse/c-k
Image is representational - see mfr. specs

BD06

Littelfuse/C&K

Standard Profile DIP ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

BD06 is a 6-position SPST standard profile DIP switch designed for address switching and logic control applications. It features an extended actuator for easy actuation, open bottom construction for solder washing, and is RoHS compliant. The switch offers a contact rating of 100 mA max at 50 V DC (carry) and 100 mA max at 5 V DC or 25 mA max at 25 V DC (switch), with a mechanical and electrical life of 10,000 make-and-break cycles at full load. Operating temperature ranges from -40°C to 85°C, with gold over nickel over phosphor bronze contacts ensuring reliable performance. Common applications include address switching for industrial controls, logic switching for computers and peripherals, and function controlling for various electronic devices.

Search Keywords: BD06

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
BD06
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Extended Slide
Actuator Length:
0.9 mm
Number of Positions:
6
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@5VDC A
Contact Plating:
N/A
Terminal Pitch:
2.54 mm

IN STOCK: 6,209

Can Ship immediately

Minimum Order Quantity: 30

Multiple: 30

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
30
$1.73
120
$1.38
270
$1.33
510
$1.29
1,020
$1.27
2,520 +
$1.26
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
