3339P-1-103LF by bourns

3339P-1-103LF

Bourns

Trimmer Potentiometer - 10K Ohm - 0.5W(1/2W) - 4(Elec)Turn - 7.62 X 6.35mm - Pin - Through Hole. ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Trimpot 3339 series 5/16-inch round cermet sealed Trimpot® Trimming Potentiometer with solderable terminals. The unique planetary drive offers precise wiper setting of a multi-turn in a single-turn package size. It can be adjustable by H-90 tool. Operating temperature ranges from -55°C to +150°C.

Search Keywords: 3339P1103LF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3339P-1-103LF
RoHS:
Yes
HTS:
8536308000
COO:
CR
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
4(Elec) Turns
Termination Style:
Pin
Power Rating:
0.5 (1/2) W
Resistance Value:
10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
6.35 x 7.62 mm
Operating Temperature:
-55 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 2,600

Ships today, if you order in

Minimum Order: 50

Multiple: 50

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
50
$3.069
100
$2.997
250
$2.946
500
$2.905
1,000
$2.894
2,500
$2.874
5,000
$2.863
7,500 +
$2.843
