5300-25-RC by bourns
Image is representational - see mfr. specs

5300-25-RC

Bourns

RF Choke Bobbin Core 100uH 10% 1KHz Ferrite 550mA 670mOhm DCR AXL Bag ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 5300-25-RC is a conformal coated RF choke from the Bourns 5300 Series, designed for use in DC/DC converters, power supplies, and general applications. This inductor features an inductance of 100 µH with ±10% tolerance, a self-resonant frequency (SRF) of 3.9 MHz, and a maximum DC resistance (DCR) of 0.67 O. It is rated for a continuous DC current (Idc) of 550 mA and has a saturation current (Isat) of 300 mA, with a temperature rise of 35°C at rated current. The component utilizes a ferrite core with enameled copper wire, tin-coated terminals, and an epoxy resin conformal coating for environmental protection. Operating across a temperature range of -55°C to +105°C and featuring 500 Vrms dielectric strength, the 5300-25-RC is ideal for applications requiring reliable RF filtering and energy storage in compact power management circuits.

Search Keywords: 530025RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
5300-25-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BULK
Inductance:
100 uH
Type:
RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
670 mOhm
Maximum DC Current:
550 mA
Protection Style:
N/A
Packaging:
Bag

IN STOCK: 12

Ships today, if you order in

Buy all 12 in-stock or the regular minimum order quantity of 50

On Order: 1,000   can ship 9/7/26

Stock lot only: 12

Minimum Order Quantity: 50

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$0.8713
50
$0.7921
250
$0.6870
500
$0.6438
1,000
$0.5974
2,500
$0.5799
5,000
$0.5572
7,500
$0.5418
10,000 +
$0.5408
Suppliers Standard Package
