5900-153-RC by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

5900-153-RC

High Current RF Choke Bobbin Core 15mH 10% 1KHz Ferrite 190mA 11.5Ohm DCR AXL ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 5900-153-RC is a high-current choke from Bourns' 5900 Series, designed for EMI filtering and power supply applications requiring high inductance values. It features a ferrite bobbin core with 15,000 µH (15 mH) inductance at 1 kHz, a maximum DC resistance of 11.5 O, and a self-resonant frequency of 0.25 MHz. The component is rated for a saturation current of 0.21 A and a continuous rated current of 0.19 A, with VW-1 rated shrink tubing covering the winding for safety and dielectric strength of 2500 Vrms. Operating over a temperature range of -40°C to +125°C, this choke is ideal for high-inductance filtering in power conversion circuits, audio equipment, and industrial power supplies where space constraints and high current handling are critical design considerations.

Search Keywords: 5900153RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
5900-153-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
864
Package Type:
TRAY
Inductance:
15 mH
Type:
High Current RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
11.5 Ohm
Maximum DC Current:
190 mA
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 2,711

Ships today, if you order in

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 216

Factory Lead-Time 16 Weeks
