RJR26FX202P by bourns
Image is representational - see mfr. specs

RJR26FX202P

Bourns

Res Cermet Trimmer 2K Ohm 10% 0.25W(1/4W) 0.1% 12(Elec)Turns 1.78mm (7.37 X 4.32 X 6.35mm) Pin Thru-Hole Tube ...

Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The RJR26FX202P is a 1/4" multiturn cermet trimming potentiometer (Trimpot) designed for precision adjustment applications in industrial environments. It features a 2 kO nominal resistance value with ±100 ppm/°C temperature coefficient, 0.25 watt power rating at 85°C, and operates across a temperature range of -65°C to +150°C. The device exhibits excellent stability with 2% or 2 ohms maximum absolute minimum resistance tolerance, infinite resolution, and 12 turns of effective travel with 200 rotational life cycles. Its sealed construction, compliance with MIL-PRF-39035 high-reliability specifications, and 0.1% failure rate rating make it suitable for demanding applications including aerospace, military electronics, and precision instrumentation where reliable fine-tuning and long-term performance are essential.

Search Keywords: RJR26FX202P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
RJR26FX202P
Unit of Measure:
Per Each
RoHS:
No
HTS:
8533408050
COO:
IE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
12(Elec) Tur ns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
2 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
7.37 x 4.32 x 6.35 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 122

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 50

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$9.75
10
$9.73
25
$9.70
50
$9.68
100
$7.26
150
$6.78
200 +
$6.64
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
