RJR26FX203P by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

RJR26FX203P

Res Cermet Trimmer 20K Ohm 10% 0.25W(1/4W) 0.1% 12(Elec)Turns 1.78mm (7.37 X 4.32 X 6.35mm) Pin Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

RJR26FX203P is a 1/4" multiturn cermet trimming potentiometer (Trimpot) designed for precision adjustment applications in industrial environments. It features a 20 kO nominal resistance value with ±10% tolerance, infinite resolution, and sealed construction rated for MIL-PRF-39035 high-reliability applications. The device operates over a temperature range of -65°C to +150°C with a temperature coefficient of ±100 ppm/°C, and delivers 0.25 watts at 85°C under 200 volts maximum. With 12 turns of effective travel, voltage adjustability of ±0.02%, and resistance adjustability of ±0.05%, this potentiometer provides exceptional precision for circuit tuning and calibration. Its robust design includes 10,000-hour load life at 85°C, 100 G shock resistance, and 20 G vibration tolerance, making it ideal for aerospace, military, telecommunications, and medical instrumentation applications requiring sealed, high-reliability trimming solutions.

Search Keywords: RJR26FX203P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
RJR26FX203P
Unit of Measure:
Per Each
RoHS:
No
HTS:
8533408050
COO:
CR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
12(Elec) Tur ns
Termination Style:
Pin
Power Rating:
0.25 (1/4) W
Resistance Value:
20 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
7.37 x 4.32 x 6.35 mm
Operating Temperature:
-65 to 150 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 158

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 50

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$9.75
10
$9.73
25
$9.70
50
$9.68
100
$7.26
150
$6.78
200 +
$6.64
