RLB9012-101KL by bourns
Image is representational - see mfr. specs

RLB9012-101KL

Bourns

Inductor Power Wirewound 100uH 10% 1KHz 20Q-Factor Ferrite 1.4A 280mOhm DCR RDL Bag ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

RLB9012-101KL is a radial leaded inductor from the Bourns RLB9012 series, designed for general-purpose power supply and DC/DC converter applications. It features a 100 µH inductance value measured at 1 kHz with ±10% tolerance, a Q reference of 20 at 0.796 MHz test frequency, and a minimum self-resonant frequency (SRF) of 3.70 MHz. The inductor is constructed with a ferrite DR core and enameled copper wire, with Cu/Ag/Sn terminals, and operates over a temperature range of -55°C to +125°C. With a maximum DC resistance of 0.280 ohms and a maximum rated DC current of 1.40 A, this RoHS-compliant component is well-suited for power electronics where reliable inductance and low losses are required.

Search Keywords: RLB9012101KL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
RLB9012-101KL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TRAY
Inductance:
100 uH
Type:
Power
Impedance:
N/A
Lead Pitch:
5 mm
Tolerance:
10 %
Technology:
Wirewound
Maximum DC Resistance:
280 mOhm
Maximum DC Current:
1.4 A
Protection Style:
N/A
Packaging:
Bag

IN STOCK: 3,250

Can Ship immediately

Minimum Order Quantity: 200

Multiple: 200

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
200
$0.2976
600
$0.2663
2,600
$0.2564
5,000
$0.2479
7,600
$0.2473
10,000
$0.2467
15,000
$0.2448
25,000 +
$0.2418
Suppliers Standard Package
