SRN6045TA-4R7M by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

SRN6045TA-4R7M

Inductor Power Semi-Shielded Wirewound 4.7uH 20% 1MHz 15Q-Factor Ferrite 4.5A 26mOhm DCR 2424 Automotive T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SRN6045TA-4R7M is a semi-shielded power inductor from Bourns designed for use in switching power supplies, DC-DC converters, and other power management circuits. The inductor features a nominal inductance of 4.7 µH with ±20% tolerance, a quality factor (Q) of 15 at 1 MHz, and a self-resonant frequency (SRF) of 40 MHz. It is rated for a continuous RMS current (Irms) of 4.5 A with a saturation current (Isat) of 6.8 A, and exhibits a DC resistance (DCR) of 26 mO. The device is constructed with a ferrite core, enameled copper wire, and magnetic epoxy resin coating, and is AEC-Q200 compliant, RoHS compliant, and halogen-free. It operates with a temperature rise of 40°C at rated current and is suitable for automotive and industrial applications requiring reliable power inductance in compact form factors.

Search Keywords: SRN6045TA4R7M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRN6045TA-4R7M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
REEL
Inductance:
4.7 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
4.5 A
Maximum DC Resistance:
0.026(Typ) Ohm
Operating Temperature:
-55 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded

IN STOCK: 6,000

Ships today, if you order in

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.4316
3,000
$0.3998
5,000
$0.3778
8,000
$0.3768
10,000
$0.3698
25,000
$0.3677
50,000 +
$0.3668
Reel Package
Log in for special pricing Click for Quote Price Match Request
