SRR1240-470M by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

SRR1240-470M

Inductor Power Shielded Wirewound 47uH 20% 100KHz 19Q-Factor Ferrite 2A 0.135Ohm DCR T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SRR1240-470M is a shielded SMD power inductor from the Bourns SRR1240 series, designed for use in DC/DC converters and power supply applications. It features a 47 µH inductance at 100 kHz with ±20% tolerance, a maximum DC resistance of 135 mO, and a self-resonant frequency of 13 MHz. The inductor supports an RMS current rating of 2.10 A and a saturation current of 1.80 A, with a maximum temperature rise of 40°C at rated Irms. Constructed with a ferrite core and enameled copper wire, it operates over a temperature range of -40°C to +125°C. This RoHS-compliant component is ideal for portable communication equipment, camcorders, and LCD TV power supplies.

Search Keywords: SRR1240470M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRR1240-470M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
800
Package Type:
REEL
Inductance:
47 uH
Type:
Power7105
Impedance:
N/A
Tolerance:
207104%
Technology:
Wirewound7103
Maximum DC Current:
2 A
Maximum DC Resistance:
0.135 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Shielded7102

IN STOCK: 11,190

Ships today, if you order in

Minimum Order Quantity: 800

Multiple: 800

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
800
$0.645
1,600
$0.644
3,200
$0.602
5,600
$0.599
8,000
$0.585
10,400
$0.584
15,200
$0.571
25,600 +
$0.569
