DPA53CM48 by carlo gavazzi

DPA53CM48

Carlo Gavazzi

3-Phase Delta Monitoring Relay, Sequence and Phase Loss, 1 SPDT Relay Output, IP20, DIN-rail mounting, Measuring Range 320 to 480 Vac, 17,5x81x67.2mm housing ...

Datasheet
RoHS Compliant
EACH Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DPA53CM48 is a 3-phase Monitoring Relay with PA66 or NORYL 17.5mm DIN-rail housing, SPDT contact, mini DIN-rail mount and screw terminals. This DPA53-series monitor relay for detection of incorrect phase sequence and phase loss. Knob-adjustable undervoltage detection. Using the front knob it can be decided the undervoltage set point of the unit. LED indication for relay and power supply ON. Green LED power supply ON and yellow LED relay ON indication <100ms ON delay and <300ms OFF delay alarm reaction time IP20 Protection rating -20 to 60°C Operating temperature range Applications Industrial

Search Keywords: DPA53CM48

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
DPA53CM48
RoHS:
Yes
HTS:
8536410060
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
EACH
Type:
Monitoring Relay
AC Coil Voltage:
380 to 480 V
DC Coil Voltage:
N/A
Coil Current:
N/A
Coil Resistance:
N/A
Dimension:
83 x 17.5 x 67.2 mm
Operating Temperature:
-20 to 60 °C
Termination Style:
Screw Terminal
Contact Arrangement:
SPDT
Contact Form:
1 Form C
Maximum Current Rating:
5 A
Mounting:
DIN Rail

IN STOCK: 6

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$149.350
3
$147.733
5 +
$134.848
