EKZN350ELL272MM25S by chemi-con
Image is representational - see manufacturer specifications
Chemi-Con Authorized Distributor

EKZN350ELL272MM25S

The EKZN350ELL272MM25S is a KZN series miniature aluminum electrolytic capacitor featuring a 2,700µF capacitance and a 35Vdc rating. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The EKZN350ELL272MM25S is a KZN series miniature aluminum electrolytic capacitor designed for high ripple current and long endurance. It provides a nominal capacitance of 2,700µF with a ±20% tolerance and a rated voltage of 35Vdc. This component is characterized by its low impedance of 0.016 Ω at 100kHz and a high rated ripple current of 3,880 mArms at 105°C. With an endurance of 10,000 hours at 105°C and a wide operating temperature range of -40 to +105°C, this RoHS2 compliant capacitor is ideal for demanding applications requiring high stability and reliability.

Search Keywords: EKZN350ELL272MM25S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Chemi-Con
Part No:
EKZN350ELL272MM25S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8532220020
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Capacitance Value:
2700 uF
Tolerance:
20 %
Operating Temperature:
-40 to 105 °C
Mounting:
Through Hole
Size:
18 x 25 mm
Termination Style:
Radial
Voltage:
35 VDC

IN STOCK: 1,500

Ships today, if you order in

Minimum Order Quantity: 25

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
25
$2.66
100
$1.96
250
$1.94
500
$1.93
1,000
$1.55
2,500
$1.53
5,000 +
$1.39
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes
