Image is representational - see mfr. specs

381LX153M025J452

Cornell Dubilier

Aluminum Electrolytic Capacitor - 15000uF ±20% - 25V - 105°C - Through Hole Snap-In - 45mm x 25mm Dia. ...

Datasheet

RoHS Compliant

CARTON Packaging

Certificate of Compliance Guarantee

DESCRIPTION

381LX153M025J452 is a high ripple, long life snap-in aluminum electrolytic capacitor designed for demanding power supply and motor drive applications. It features a capacitance of 15000 µF with a rated voltage of 25 Vdc (32 Vdc surge) and operates over a temperature range of -40°C to +105°C. The capacitor exhibits a maximum ESR of 0.036 ohms at 120 Hz and 0.031 ohms at 20 kHz, with ripple current ratings of 3.60 A at 120 Hz and 4.10 A at 20 kHz at +105°C. With a nominal size of 25 × 45 mm and an endurance life of 3000 hours at full load at 105°C, this capacitor is ideal for switching power supply input/output circuits and motor-drive bus capacitor applications where high ripple capability and extended service life are required.

Product Highlights:

Potential Applications:

Search Keywords: 381LX153M025J452

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Cornell Dubilier

Part No:

381LX153M025J452

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8532220040

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

100

Package Type:

CARTON

Capacitance Value:

15000 uF

Tolerance:

20 %

Operating Temperature:

-40 to 105 °C

Mounting:

Through Hole

Voltage:

25 VDC

IN STOCK: 545

Ships today, if you order in

BONDED Quantity: 0

Manufacturer Stock: 0

Stock lot only:

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 750

Multiple: 1

Factory Lead-Time 20 Weeks

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.

Price (USD)

Qty

Unit Price

$7.25

250

$7.23

500

$7.21

750

$7.19

1,500

$3.80

2,250

$2.61

3,000 +

$2.55
