209-2MS by cts corporation

209-2MS

CTS Corporation

Switch DIP ON OFF SPST 2 Raised Slide 0.1A 20VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The CTS CORP part 209-2MS is a versatile and reliable DIP switch for various applications. This switch features a single pole/single throw (SPST) configuration with a two-position raised slide that can be easily switched between ON and OFF positions. With a current rating of 0.1A and a voltage rating of 20VDC, this DIP switch is suitable for low-power electrical circuits. It is designed for through-hole PCB mounting, with sturdy PC pins ensuring secure and reliable connections. The 209-2MS DIP switch is built to last, with a durability of 2000 cycles, making it ideal for long-term usage. With a pitch of 2.54mm, it is compatible with standard DIP switch layouts. This DIP switch is packaged in a convenient tube format, allowing for easy storage and transportation. Trust CTS CORP part 209-2MS to provide reliable and efficient circuit switching capabilities for your projects.

Search Keywords: 2092MS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CTS Corporation
Part No:
209-2MS
RoHS:
Yes
HTS:
8536509050
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1020
Package Type:
Tube
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
0.25 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@20VDC A
Contact Plating:
Gold
Terminal Pitch:
2.54 mm

IN STOCK: 22,019

Ships today, if you order in

Minimum Order: 50

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
50
$0.6118
500
$0.4478
1,020
$0.4317
3,060
$0.4184
5,100
$0.4163
8,160
$0.4142
15,300
$0.4121
25,500 +
$0.4100
Suppliers Standard Package
