F1500CA15 by curtis industries

F1500CA15

Curtis Industries

Power Line Filter 50Hz/60Hz 15A 250VAC Quick Connect Screw Mount ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

F1500CA15 is a high-performance RFI filter designed for single-phase power supply applications requiring electromagnetic interference suppression. It features an IEC connector on the line side and 0.250" quick-connect terminals on the load side, with a compact "L" circuit configuration that provides both common and differential mode filtering. The filter is rated for 15A at 250VAC (50/60 Hz) with a maximum ambient temperature of 40°C at rated current, and offers high-inductance design for greater attenuation across a wide frequency range. Minimum insertion loss specifications include 26 dB at 0.15 MHz (common mode) and 35 dB at 0.15 MHz (differential mode), with performance extending to 30 MHz. This filter is ideal for linear and switching power supply applications where cost-effective RFI suppression and compact form factor are essential.

Search Keywords: F1500CA15

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Curtis Industries
Part No:
F1500CA15
Unit of Measure:
Per Each
RoHS:
Yes
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Mounting:
Screw Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
15 A
Operating Frequency:
50,60 Hz
Operating Temperature:
N/A
Dimension:
50.8 x 38.2 mm

IN STOCK: 11

Can Ship immediately

MOQ for out of Stock Qty: 3

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$91.79
3
$91.57
5
$82.41
8
$72.11
10 +
$70.67
