06AN2 by delta thermal / emi / solenoids
Image is representational - see mfr. specs

06AN2

Delta Thermal / EMI / Solenoids

Power Entry Module Filtered M 3 POS 250VAC 6A Switch/Fuse ST 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 06AN2 is a metal-case power entry module designed to meet IEC publication 320 Class 1 standards, incorporating an IEC connector, fuse holder, single-pole power switch, and voltage selector switch in a compact all-in-one unit. It features nickel-plated brass pins and soldering terminals with a snap-in mounting design compatible with panel thicknesses of 0.04 inch to 0.07 inch. The module is rated for 115VAC/250VAC operation with a maximum leakage current of 2 µA at 115VAC/60Hz and 5 µA at 250VAC/50Hz, and provides dielectric strength of 2250VDC line-to-ground and 1450VDC line-to-line. The single-pole power switch is UL/CSA approved at 6A for 125VAC/250VAC with an electrical lifetime of 50,000 cycles and maximum in-rush current of 70A. This design provides significant space and cost savings compared to assembling individual components, making it ideal for industrial equipment, medical devices, and consumer electronics requiring standardized power entry solutions.

Search Keywords: 06AN2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
06AN2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8548000000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
280
Type:
Filtered
Body Orientation:
Straight
Gender:
M
Mounting:
Snap-In
Termination Method:
Solder
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
6 A
Operating Frequency:
N/A
Operating Temperature:
N/A

IN STOCK: 325

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
5
$11.11
25
$10.07
50
$9.62
100
$9.34
280
$8.84
560
$8.60
1,120 +
$8.47
Suppliers Standard Package
