AFC0612DB-F00 by delta thermal / emi / solenoids

AFC0612DB-F00

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 60x15mm - 12VDC - 29.24CFM - 3.96W - 0.33A - 47.5dBA - 7200RPM - Ball Bearing - PWM ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AFC0612DB-F00 is a DC Axial Fan Voltage - Rated 12VDC Size / Dimension Square - 60mm L x 60mm H Width 15.00mm Air Flow 29.2 CFM (0.818m³/min) Static Pressure 0.517 in H2O (128.8 Pa) Bearing Type Ball Fan Type Tubeaxial Features PWM Control, Speed Sensor (Tach) Noise 47.5 dB(A) Power (Watts) 3.96W RPM 7200 RPM Termination 4 Wire Leads Operating Temperature 14 ~ 140°F (-10 ~ 60°C) Approvals CE, TUV, UL Weight 0.098 lb (44.45g) Current Rating (Amps) 0.330A Voltage Range 8 ~ 13.2VDC Material - Frame Plastic Material - Blade Plastic Lifetime @ Temp. 70000 Hrs @ 40°C

Search Keywords: AFC0612DBF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFC0612DB-F00
RoHS:
Yes
HTS:
8414599080
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
630
Package Type:
Bulk
Category:
DC Fan
Dimension:
60 x 60 x 15 mm
Voltage Rating:
12 V
Power Rating:
5.4 W
Maximum Airflow:
51.5 CFM
Noise Level:
51.5 dB
Tachometer Signal:
Yes
Special Features:
Tachometer Output
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 60 °C

IN STOCK: 983

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 32 Weeks
