556-1603-304F by dialight
Image is representational - see manufacturer specifications
Dialight Authorized Distributor

556-1603-304F

The 556-1603-304F is a green LED panel mount indicator featuring a flat lens and a white nickel plated brass housing for visual signaling. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 556-1603-304F is a standard panel mount indicator from the 556 series, designed for clear visual signaling. It features a green LED that provides a typical luminous intensity of 41,500 mcd while operating at 12 VDC with a typical current draw of 60 mA. The indicator is constructed with a durable, white nickel plated brass housing, a flat transparent polycarbonate lens, and connects via 6-32 screw terminals. Designed for a 1.0-inch mounting hole, this indicator is IP66 and NEMA 4X rated, making it highly durable for outdoor applications. It is well-suited for use in instrument panels, safety applications, transportation signaling, and display lighting.

Search Keywords: 5561603304F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
556-1603-304F
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Color:
Green
Dimension:
46.23 x 28.5 mm

IN STOCK: 83

Ships today, if you order in

MOQ for out of Stock Qty: 6

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
1
$52.05
6
$47.46
11
$46.10
16
$45.76
21 +
$45.65
