100DP3T1B1M2QEH by e-switch

100DP3T1B1M2QEH

E-Switch

Toggle Switch - Miniature - DPDT - Standard Actuator - PC Mount -Silver - Epoxy Sealed

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 100DP3T1B1M2QEH is a miniature toggle switch with standard actuator. Contact arrangement is DPDT (ON-OFF-ON). Contacts rating is: 5A with resistive load @ 120VAC or 28VDC; 2A with resistive load @ 250VAC.

Search Keywords: 100DP3T1B1M2QEH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
100DP3T1B1M2QEH
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
96
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 11.43 x 29.69 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 498

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 14 Weeks

Price (CAD)

Qty
Unit Price
5
$7.289
96
$4.793
192
$4.762
288
$4.640
576
$4.441
1,056
$4.273
2,592
$4.256
5,088 +
$4.227
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
