Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

100SP4T1B1M2QEH

The 100SP4T1B1M2QEH is a panel-mount, SPDT toggle switch with a 3-position, momentary-off-momentary function. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 100SP4T1B1M2QEH is a single-pole, double-throw (SPDT) toggle switch designed for panel mounting. It features a momentary-on / off / momentary-on function and offers a dual contact rating of 5A at 120VAC or 28VDC, and 2A at 250VAC. This switch is built for reliability with an electrical life of 6,000 make-and-break cycles at full load and silver-plated terminals. It ensures robust performance with a dielectric strength of 1,000 V RMS and an operating temperature range of -40°C to 85°C. Suitable for industrial controls and instrumentation, it mounts via a 1/4-40 UNS-2A threaded bushing and comes with required hardware.

Search Keywords: 100SP4T1B1M2QEH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
100SP4T1B1M2QEH
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
96
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
(On) Off (On)
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 6.86 x 29.69 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 1,177

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$5.33
96
$3.68
192
$3.64
288
$3.55
576
$3.40
1,056
$3.25
2,592
$3.06
5,088 +
$3.05
