320.02E11.08BLU by e-switch
Image is representational - see mfr. specs

320.02E11.08BLU

E-Switch

Tactile Switch - SPST NO - 50VDC - 25mA - 135 (+/-) 50 gf - Blue Button - Through Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 320.02E11.08BLU is an SPST (Single Pole Single Throw) tactile pushbutton switch featuring a blue cap and designed for standard PCB mounting applications. The switch is rated for 25 mA at 50 VDC and has an operating force of 135±50 gF with a travel to make of 0.7 mm, providing reliable tactile feedback for user input. The device features a 2.54 mm pitch PCB pin spacing with Ø1.22 mm PCB pins and Ø1.00 mm alignment pins, ensuring precise positioning on standard circuit boards. The body dimensions are 10.30 mm square with a cap diameter of Ø11.9 mm, and the terminal dimensions are 5.08 × 5.08 × 2.39 mm with 1.00 × 0.40 mm typical terminal cross-section. This switch is commonly used in consumer electronics, industrial control panels, and embedded systems where compact, reliable momentary switching is required.

Search Keywords: 32002E1108BLU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
320.02E11.08BLU
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
162
Dimension:
12.4mm x 12.4mm x 14.413763mm
Mounting:
Through Hole13759
Pole Throw Configuration:
SPST13761
Switch Configuration:
N.O.13768
Actuator Style:
Round Button13737
Contact Rating @ Voltage:
0.02513752A@50VDC
Body Orientation:
Straight13740
Seal Location:
N/A

IN STOCK: 327

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 648

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
5
$15.06
100
$15.02
250
$14.98
500
$14.95
648
$14.90
1,296
$7.61
1,944
$5.18
2,592 +
$5.08
