1803455 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1803455

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 5 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

This PHOENIX CONTACT part 1803455 is a PCB header with a nominal current of 8 A and a rated voltage of 160 V (III/2). It has a nominal cross section of 1.5 mm² and comes with 5 positions. The pitch of this header is 3.81 mm and it is designed in a green color. The contact surface is coated with tin for enhanced conductivity. This PCB header is suitable for wave soldering mounting and has a pin layout in linear pinning style. The solder pin measures 3.4 mm.

Search Keywords: 1803455

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803455
Alias/AKA:
1803455
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
5
Maximum Voltage Rating:
160@IEC,300@UL V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 524

Ships today, if you order in

On Order: 1,000   can ship 11/16/26
On Order: 1,000   can ship 5/24/27

Minimum Order Quantity: 25

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
25
$1.92
100
$1.53
250
$1.50
500
$1.48
1,000
$1.47
2,500
$1.46
5,000
$1.45
7,500 +
$1.44
