LS0851504F085C1A by e-switch
Image is representational - see mfr. specs

LS0851504F085C1A

E-Switch

Switch Snap Action N.O./N.C. SPDT Simulated Roller Lever 15A 250VAC 0.83N Screw Mount Quick Connect ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

LS0851504F085C1A is an SPDT (Single Pole Double Throw) pushbutton switch designed for general-purpose switching applications. The switch is rated for 15A at 125/250VAC and features an operating force of 85±30 grams with a pre-travel of 5.2 mm maximum and an operating point of 19.0±1.5 mm. It delivers a minimum electrical life of 50,000 cycles and a typical mechanical life of 1,000,000 cycles, with contact resistance maintained at 100 milliohms maximum and insulation resistance of 100 megaohms minimum. The switch operates reliably across a temperature range of -25°C to +85°C and meets UL/CUL approval standards, making it suitable for industrial control panels, appliances, and consumer electronics requiring durable, reliable switching performance.

Search Keywords: LS0851504F085C1A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
LS0851504F085C1A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
High Temperature Polybutylene Terephthalate/Simulated Roller Lever
Contact Rating @ Voltage:
15@250VAC@(cUL/UL/VDE) A
Maximum Movement Differential:
N/A
Operating Force:
0.83 N
Termination Style:
Quick Connect
Dimension:
47.45 x 10.3 x 29.6 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 400

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
100
$1.58
300
$1.43
500
$1.36
1,000
$1.28
2,500
$1.27
5,000
$1.15
7,500
$1.14
10,000 +
$1.13
Suppliers Standard Package
