BK/ABC-5-R by eaton electronics / bussmann
Image is representational - see mfr. specs

BK/ABC-5-R

Eaton Electronics / Bussmann

Fuse Miniature 5A 250V Fast 2-Pin Cartridge Holder ...

Datasheet
RoHS Compliant
Bulk Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BK/ABC-5-R is a fast-acting ceramic tube fuse designed for electrical circuit protection in AC and DC applications. It features a voltage rating of 250V AC (125V DC), with an interrupting capacity of 10,000 amps at both AC and DC ratings, and a typical DC cold resistance of 0.031 O. The fuse exhibits fast-acting characteristics with an opening time of 4 hours minimum at 100% of rated current, 60 minutes maximum at 135%, and 120 seconds maximum at 200% of rated current. With a typical pre-arc I²t value of 32.83 and a voltage drop of 0.22 mV at rated current, this fuse is suitable for industrial control circuits, power distribution systems, and equipment protection where reliable overcurrent protection is required.

Search Keywords: BKABC5R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
BK/ABC-5-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536100040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bulk
Type:
Miniature
Fuse Size:
1/4 x 1-1/4 in
Acting:
Fast
Current Rating:
5 A
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
125 V
Fuse Material:
Ceramic
Mounting:
Holder

IN STOCK: 1,570

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
10
$1.037
50
$0.955
300
$0.864
500
$0.838
1,000
$0.803
2,500
$0.756
5,000
$0.696
7,500 +
$0.677
