A70QS50-14F by ferraz shawmut
Image is representational - see mfr. specs

A70QS50-14F

Ferraz Shawmut

The A70QS50-14F is a 50A, 700V French cylindrical semiconductor fuse designed for high-speed short-circuit protection. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The A70QS50-14F is a 50A Amp-Trap® French cylindrical semiconductor fuse that provides high-speed short-circuit protection. It is rated for 690VAC and 700VDC, with high interrupting ratings of 200kA AC and 100kA DC. This 14x51mm fuse features a very low melting I²t of 280 A²s, a maximum clearing I²t of 1500 A²s at 700VAC, and a power loss of 11.6W at its rated current. With its aR characteristic and superior cycling ability, it is ideal for protecting small inverters, UPS systems, and motor drives.

Search Keywords: A70QS5014F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Ferraz Shawmut
Part No:
A70QS50-14F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536100040
COO:
TN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Blade
Fuse Size:
14 x 51 mm
Acting:
N/A
Current Rating:
50 A
Maximum AC Voltage Rating:
760 V
Maximum DC Voltage Rating:
700 V
Fuse Material:
N/A
Mounting:
Holder

IN STOCK: 0

On Order: 20   can ship 7/13/26

MOQ for out of Stock Qty: 3

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
1
$102.55
3
$101.01
5
$90.91
8
$79.55
10 +
$77.95
Suppliers Standard Package
