SCBRX012XXABXA by te connectivity / agastat brand
Image is representational - see manufacturer specifications
TE Connectivity / Agastat Brand Authorized Distributor

SCBRX012XXABXA

Electromechanical Relay 125VDC 120VAC 10A DPDT (50x50x83)mm Socket Time Delay Relay ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

Electromechanical Relay 125VDC 120VAC 10A DPDT (50x50x83)mm Socket Time Delay Relay

Product Highlights:

  • SCB Specification Grade Precision Timing Series
  • Time Delay Relay
  • Input Voltage = 120 VAC
  • Input Voltage = 125 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O

Search Keywords: SCBRX012XXABXA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
SCBRX012XXABXA
Alias/AKA:
1-1437467-4
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536490050
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Mounting:
Socket
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
120 V
AC Coil Voltage:
120 V
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
8-Pin Circular Plug
Time Range:
0.5 to 15 sec
Life Cycle:
Discontinued
   This product has been discontinued by the supplier
