DR30B5-EB by fuji electric
Image is representational - see manufacturer specifications
Fuji Electric Authorized Distributor

DR30B5-EB

Audio Buzzer 12VDC 24VDC 25DCmA/40ACmA 60VDC/60VAC 70dBA 2400Hz to 3300Hz Screw Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The DR30B5-EB is a 30mm-diameter electronic sound buzzer designed for industrial control applications. It features an LED operation indicator (red), intermittent/continuous sound selection, and operates at 12 to 24V AC/DC without a transformer. The buzzer produces a sound level of 90dB at 0.1m and 70dB at 1m, with a frequency range of 2.4 to 3.3kHz and an intermittent cycle of approximately 170 cycles/min. It has a rated insulation voltage of 60V AC/DC without transformer, dielectric strength of 1000V AC for 1 minute, and operates reliably across an ambient temperature range of -20 to +60°C with 1000 hours of durability. The DR30B5-EB is ideal for alarm systems, machinery control panels, and warning applications where audible alerts are required in industrial environments.

Search Keywords: DR30B5EB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Fuji Electric
Part No:
DR30B5-EB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8531809041
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Minimum Sound Pressure:
70 dBA
Mounting:
Panel Mount

IN STOCK: 7

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
1
$82.77
5
$74.40
10
$72.33
25
$66.79
50
$66.62
100
$65.14
250 +
$62.83
