71BDF30-03-1-AJN by grayhill
Image is representational - see mfr. specs

71BDF30-03-1-AJN

Grayhill

A Series 71, 3-deck, 1-pole non-shorting rotary switch with a 30° angle of throw, adjustable stops, and PC mount terminals. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 71BDF30-03-1-AJN is a multi-deck rotary switch from the Series 71 family, designed for versatile circuit control. It features a 1/4-inch diameter shaft, a 30° angle of throw, and PC mount terminals for direct board installation. The switch is configured with three decks and one pole per deck, utilizing non-shorting (break-before-make) contacts. Its key feature is the adjustable stop mechanism, which allows the user to define the number of active positions from 2 to 12. This adaptability makes it ideal for prototyping, test equipment, and industrial control panels where position requirements may vary.

Search Keywords: 71BDF30031AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
71BDF30-03-1-AJN
Alias/AKA:
71BDF30-03PAJN
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
1213872
Pole Throw Configuration:
SP12T13875
Actuator Length:
9.53 mm
Dimension:
22.23mm x 47.85mm x 18.0813878mm
Actuator Style/Diameter:
Flatted Shaft/6.3613842
Mounting:
Panel Mount/Through Hole13870
Body Orientation:
Right Angle13849
Terminal Type:
PC Pins13888
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.3@115VAC A

IN STOCK: 0

On Order: 134   can ship 7/20/26

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
1
$74.97
5
$74.23
10
$73.69
25
$59.93
50
$59.45
100
$59.15
250 +
$58.85
Log in for special pricing Click for Quote Price Match Request
