90B03ST by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

90B03ST

Switch DIP ON OFF SPST 3 Recessed Slide 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 90B03ST is a 3-position thru-hole DIP switch designed for machine insertion with a molded sealed base and optional top tape seal. It features high-pressure, reliable contacts with a contact resistance of =20 mO initially and =100 mO after life testing, ensuring consistent electrical performance. The switch has a length of 0.370 inches (9.4 mm) and is designed for 0.100 × 0.300 inch on-center holes, with a mechanical life rating of 2,000 operations per switch position. Operating over a temperature range of -40°C to +85°C with an insulation resistance of 5,000 MO initially and 1,000 MO after life, the 90B03ST is ideal for applications requiring reliable configuration settings in industrial equipment, telecommunications, and consumer electronics where compact, durable switching is essential.

Search Keywords: 90B03ST

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
90B03ST
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
47
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Recessed Slide
Actuator Length:
0 mm
Number of Positions:
3
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.15@30VDC A
Contact Plating:
Gold/Nickel Barrier
Terminal Pitch:
2.54 mm

IN STOCK: 564

Ships today, if you order in

Minimum Order Quantity: 47

Multiple: 47

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
47
$5.40
94
$5.01
141
$4.73
282
$4.47
517
$4.20
1,034
$3.62
2,538
$3.23
5,029 +
$2.01
