M80-8890405 by harwin
Image is representational - see manufacturer specifications
Harwin Authorized Distributor

M80-8890405

Datamate L-Tek DIL Female Large Bore Crimp Connector, gold clip + gold shell, 2+2 contacts ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The M80-8890405 is a Datamate 2 mm pitch crimp DIL socket assembly with large bore (22 AWG) designed for reliable electrical interconnection in industrial and electronic equipment. It features a glass-filled PBT UL94V-0 moulding with beryllium copper clips and copper alloy shell, finished with nickel and 0.30 µm gold clip with 0.28 µm gold shell plating. The connector is rated for 3.0 A maximum at 25 °C and 2.2 A at 85 °C, with a working voltage of 120 V AC/DC and voltage proof of 360 V AC/DC, delivering initial contact resistance of 20 mO maximum and insulation resistance of 1000 mO minimum. It withstands 500 mechanical operations with insertion and withdrawal forces of 2.8 N maximum and 1.8 N maximum respectively, and operates reliably across -55 °C to +125 °C. This connector is ideal for applications requiring robust, repeatable mating cycles in harsh environments and demanding electrical performance.

Search Keywords: M808890405

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Harwin
Part No:
M80-8890405
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
GB
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1

IN STOCK: 144

Ships today, if you order in

Minimum Order Quantity: 10

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
10
$3.32
50
$2.79
250
$2.49
500
$2.40
1,000
$2.39
2,500
$2.26
5,000
$2.25
7,500 +
$2.24
Log in for special pricing
