102MG11

The 102MG11 is a sintered Alnico VIII bar magnet with a threaded shaft, designed for actuating Hall-effect and magnetoresistive sensor ICs. ...

Datasheet

RoHS Compliant

DESCRIPTION

The 102MG11 is a sintered Alnico VIII bar magnet designed for sensor actuation. It measures 17.02 mm in length by 7.87 mm in diameter and includes an 8 x 32 threaded shaft for easy installation. This magnet offers good physical strength, excellent resistance to demagnetization, and operates reliably over a temperature range of -40 °C to 140 °C. It provides a typical magnetic field of 470 Gauss at a 2.54 mm gap distance. Common applications include industrial and medical equipment for tasks like position sensing, speed measurement, and lid closure detection.

Product Highlights:

Wide variety of sizes and shapes
Wide variety of magnetic materials
Threaded bushings available on some listings for easy installation

Potential Applications:

Search Keywords: 102MG11

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Honeywell

Part No:

102MG11

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

85051100

COO:

ECCN:

EAR99
