111SM1-T by honeywell

111SM1-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SM Series, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Straight Lever Actuator, Solder Termination ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 111SM1-T Honeywell Snap Action Switch is a sub-miniature basic micro switch. Compact and lightweight, this Honeywell Snap Action Switch delivers long mechanical life. It features an elongated mounting hole for more accurate and easier mounting. Snap Action Switches, also known as micro switches, are switch devices that are used to open or close an electrical circuit at a rapid speed.

The Honeywell 111SM1-T switch comes with a choice of actuation to provide design flexibility. With an operating temperature range between 55 °C to 125 °C [-67 °F to 257 °F], this On-Off Switch offers reliable performance even in harsh environments. These highly sensitive switches are very often used in applications including aerospace, appliances, vending machines, timing devices, office equipment, computer and business equipment, test instruments, HVAC systems, manually operated devices, and valves.

Product Highlights:

  • Choice of operating characteristics (sensitive differential travel as low as 0.0254 mm [0.001 in] maximum, low operating force to 0.56 N [2.0 oz.] maximum)
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 11 A)
  • MIL-PRF-8805 qualified listings available
  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Choice of electrical termination (solder, quick connect, PCB)

Potential Applications:

  • Aerospace
  • Instrumentation
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: 111SM1T

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
111SM1-T
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Leaf Lever
Contact Rating @ Voltage:
5 A
Maximum Movement Differential:
0.76 mm
Operating Force:
1.95 N
Termination Style:
Solder
Dimension:
19.8mm x 6.4mm x 13.7mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 34

Ships today, if you order in

On Order: 926   can ship 12/25/25

Minimum Order: 5

Factory Lead-Time 15 Weeks

Price (CAD)

Qty
Unit Price
5
$19.034
25
$18.483
50
$17.656
100
$16.752
300
$16.324
500
$16.247
1,000 +
$16.171
