1HS1 by honeywell

1HS1

Honeywell

MICRO SWITCH™ Hermetically Sealed Large Basic Switches: HS Series, Single Pole Double Throw (SPDT) 1 A 115 Vac, Metal Enclosure, Integral Lever Actuator with Wobblefram Actuator Seal, Switch will Withstand Temperature of 121 °C [250 °F], Binding Head Screw Termination with Integral Washers, Mounting Holes with Accept Pins or Screws, UL, CSA, Military Part Number MS25011-1 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap Action Switches are switch devices that are used to open or close an electrical circuit at a rapid speed. These devices are also known as micro switches and work with lever, pushbutton, and roller actuators. They are generally used in adverse gas or vapor environments, aircraft and helicopters, industrial valve control equipment, and steam cleaning of food processing machines, among others.

1HS1 Snap Action Switch from Honeywell is a hermetically-sealed switch. This Honeywell Switch is specially designed for industrial applications which require maximum number of electrical rating and sealing. It is not sensitive to altitude or pressure changes and delivers reliable and stable performance. The power load switching capability of this SPDT Switch is 25 A at 28 Vdc.

Product Highlights:

  • Choice of actuation
  • Not sensitive to changes in altitude or pressure
  • Power load switching capability to 25 A at 28 Vdc
  • Hermetically sealed per MIL-PRF-8805, design symbol 5
  • Broad temperature tolerance range of -55 °C to 125 °C [-67 °F to 250 °F]
  • High temperature construction for use to 149 °C [300 °F]

Potential Applications:

  • Adverse gas or vapor environments
  • Aircraft and helicopters
  • Steam cleaning of food processing machines
  • Moist, dusty, or oily environments
  • Industrial valve control

Search Keywords: 1HS1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1HS1
RoHS:
Yes
HTS:
85365080
COO:
US
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Simulated Roller Lever
Contact Rating @ Voltage:
25@28VDC A
Maximum Movement Differential:
0.51 mm
Operating Force:
6.12 N
Termination Style:
Screw
Dimension:
49.78 x 17.45 x 29.97 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 150

Can Ship immediately

Factory Lead-Time 6 Weeks

Price (CAD)

Qty
Unit Price
1
$567.945
3
$565.111
5 +
$537.042
