2NT1-5

MICRO SWITCH™ Toggle Switches: NT Series, Double Pole Double Throw (DPDT), 3 Position (Mom. On - Off - On), Screw Terminal, Standard Lever ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

2NT1-5 Toggle Switch from Honeywell features a high-quality rugged construction with completely sealed switching chamber. The Easy-Start threaded bushing of this switch enables quick alignment of mounting nut to avoid chances of cross threading. This 3 position toggle switch can be used where panels are exposed to splashes, hosedowns, or outdoor environments.

Toggle Switches are devices that are manually actuated by means of a projecting lever, such as a mechanical lever, handle or by a rocking mechanism. These electrical switches are available in many different sizes and configurations. Honeywell Toggle Switch 2NT1-5 is often used in applications like material-handling equipment, factory-floor control units, aerial lifts, scissor lifts, truck mounted tele-handlers, cranes, construction equipment, agriculture equipment, and machine tool equipment.

Product Highlights:

  • High-quality rugged construction
  • Completely sealed switching chamber
  • Easy-Start threaded bushing
  • DPDT Circuitry
  • 3 position action
  • On Off On switch Configuration
  • Thermoplastic case
  • NEMA 3, 3R, 4, and 13
  • UL recognized, CSA certified, CE approved

Potential Applications:

  • Aerial lifts, scissor lifts, truck mounted tele-handlers, and cranes
  • Construction equipment
  • Agriculture equipment
  • Material-handling equipment
  • Factory-floor control units
  • Machine tool equipment manufacturers

Search Keywords: 2NT15

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2NT1-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650070000
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
ON OFF (ON)
Contact Rating @ Voltage:
18@28VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.4mm x 22.6mm x 63.6 mm
Operating Temperature:
-40 to 71 °C
