3AC6-D8 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

3AC6-D8

MICRO SWITCH™ Door Switches: AC Series, Single Pole Double Throw (SPDT), 15.1 A 125/250 Vac, 3 Position (Push-Momentary, Pull-Maintained), 6-32 UNC Threaded Steel Rod Actuator, Supplied with V3 Basic Switch, 4,75 mm x 0,50 mm [0.187 in x 0.020 in] Quick Connect Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HONEYWELL 3AC6-D8 is a MICRO SWITCH Door Switch from the AC Series, featuring a Single Pole Double Throw (SPDT) configuration with a 15.1 A 125/250 Vac rating. This switch offers 3 positions: Push-Momentary, Pull-Maintained, and comes with a durable 6-32 UNC Threaded Steel Rod Actuator. It is equipped with a V3 Basic Switch and features 4.75 mm x 0.50 mm [0.187 in x 0.020 in] Quick Connect Termination for easy installation. Ideal for various industrial applications, this reliable door switch ensures smooth and efficient operation.

Product Highlights:

  • Automatically cuts power when service door or drawer is opened
  • Choice of momentary, maintained or pull-to-cheat actuation
  • Versatile mounting bracket for side or end mounting
  • Current rating ranges from 5 A to 25 A
  • Available with one or two SPDT switches
  • UL recognized versions available
  • Choice of termination

Potential Applications:

  • Appliances
  • Vending machines
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment

Search Keywords: 3AC6D8

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
3AC6-D8
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Type:
Door Interlock
Actuator Style:
Rod
Pole Throw Configuration:
SPDT
Maximum Current Rating:
15.1@250VAC A
Terminal Type:
Quick Connect
Operating Temperature:
-18 to 82 °C
IP Rating:
N/A
Dimension:
52.32 x 12.7 x 45.97 mm
Switch Configuration:
N.O./N.C.
Body Orientation:
Straight

IN STOCK: 48

Ships today, if you order in

MOQ for out of Stock Qty: 13

Factory Lead-Time 21 Weeks

Price (USD)

Qty
Unit Price
1
$253.16
5
$245.35
10
$242.92
13
$242.31
25
$241.71
38
$241.10
50 +
$240.49
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
