BX2P4L by honeywell
Image is representational - see mfr. specs

BX2P4L

Honeywell

The BX2P4L is a low-differential, momentary side rotary limit switch with a stainless steel housing, designed for use in hazardous locations. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BX2P4L is a hazardous location limit switch from the MICRO SWITCH™ BX2 Series, featuring a corrosion-resistant stainless steel housing. It provides 2NC-2NO DPDT snap-action switching with silver contacts and is designed for low differential travel of 4° maximum. This momentary, side-rotary switch has a maximum operating torque of 0.45 Nm, a maximum pretravel of 9°, and a minimum overtravel of 66°. It operates reliably in a wide temperature range from -40 °C to 70 °C and includes a 0.75-14 NPT conduit entry. With its rugged, weather-sealed construction, the BX2P4L is ideal for demanding applications in explosive environments such as chemical plants, off-shore drilling sites, and pipelines.

Search Keywords: BX2P4L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BX2P4L
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Explosion Proof
Actuator Style:
Side Rotary
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
N/A
Maximum Current Rating:
N/A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 6, 7, 9, 13
Body Orientation:
Right Angle

IN STOCK: 5

Can Ship immediately

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
1
$3,162.35
3
$2,998.07
5 +
$1,888.79
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
