BZ-2R5551-A2 by honeywell

BZ-2R5551-A2

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, 3,96 mm [0.156 in] Diameter Pin Plunger with Elastomer Plunger Seal, Dust and Splash Resistant Cover to Case Seal, Binding Head Combination Screw Termination with Cup Washers, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part BZ-2R5551-A2 is a MICRO SWITCH Premium Large Basic Switch featuring a single pole double throw (SPDT) configuration. It is designed to handle up to 15 A at 125/250 Vac and 16 A at 250 Vac with a 3.96 mm [0.156 in] diameter pin plunger and elastomer plunger seal. This switch is equipped with a dust and splash resistant cover to case seal, and binding head combination screw termination with cup washers. The mounting holes on this switch can accept pins or screws, and it is UL, CE, CSA, and ENEC certified.

Search Keywords: BZ2R5551A2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2R5551-A2
RoHS:
Yes
HTS:
85365090
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plunger
Contact Rating @ Voltage:
186.42 A
Maximum Movement Differential:
0.06 mm
Operating Force:
4.17 N
Termination Style:
Screw
Dimension:
49.28mm x 17.45mm x 26.92 mm
Body Orientation:
Straight
IP Rating:
IP64
