BZ-2RQ66 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

BZ-2RQ66

MICRO SWITCH™ Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A at 250 Vac, Overtravel Plunger Actuator, 2,5 N - 3,61 N [9 - 13 oz] Operating Force, Silver Contacts, Screw Termination ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

A Snap Action Switch is a type of momentary contact micro switch which operates at a rapid speed as it takes very little force or stimulus to operate. These highly sensitive switches are widely used in irrigation systems, semi-trailer trucks, timing devices and office equipment. This Plunger Micro Switch is also used in test instruments, medical and dental equipment, HVAC equipment, manually operated devices and valves.

BZ-2RQ66 Snap Action Switch from Honeywell comes with low operating force and differential travel to deliver reliable functionality. Featuring a choice of actuation, termination and operating characteristics, this SPDT snap action switch is ideal for a variety of industrial and mechanical applications. This Honeywell switch has a long mechanical life of up to 20,000,000 cycles at a 95% survival rate.

Product Highlights:

  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Choice of actuation, termination and operating characteristics
  • Accepted world-wide standard "Large Basic" switch
  • Low operating force and differential travel
  • Long mechanical life up to 20,000,000 cycles at 95% survival

Potential Applications:

  • Irrigation systems
  • Semi-trailer trucks
  • Timing devices
  • Office equipment
  • Test instruments
  • Medical/dental equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: BZ2RQ66

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2RQ66
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/High Overtravel Plunger
Contact Rating @ Voltage:
186.42 A
Maximum Movement Differential:
0.05 mm
Operating Force:
3.61 N
Termination Style:
Screw
Dimension:
49.28 x 17.45 x 47.63 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 109

Ships today, if you order in

On Order: 400   can ship 2/15/27

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$43.42
5
$37.96
10
$36.32
25
$34.21
50
$33.52
200
$32.92
400 +
$32.84
Supplier's Standard Package
Log in for special pricing
