DT-2RS1-A7 by honeywell
Image is representational - see mfr. specs

DT-2RS1-A7

Honeywell

MICRO SWITCH™ Specialty Large Basic Switches: DT Series, Double Pole Double Throw (DPDT), 10 A 125/250 Vac, Additional Overtravel Pin Plunger, 3,3 to 5,6 N [12 to 20 oz] Higher Operating Force, 4-40 UNC Round Head Screw Termination with Lock Washers, Flexible Insulator, Mounting Holes will Accept Pins or Screws, UL, CSA, FAA-PMA ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MICRO SWITCH™ Specialty Large Basic Switches: DT Series, Double Pole Double Throw (DPDT), 10 A 125/250 Vac, Additional Overtravel Pin Plunger, 3,3 to 5,6 N [12 to 20 oz] Higher Operating Force, 4-40 UNC Round Head Screw Termination with Lock Washers, Flexible Insulator, Mounting Holes will Accept Pins or Screws, UL, CSA, FAA-PMA

Product Highlights:

  • Mounting interchangeability with type Z switches
  • Rated for 10 A at 240 Vac
  • Temperature tolerance to 82 C [180 F]
  • Design permits several wiring combinations

Potential Applications:

  • Irrigation systems
  • Semi-trailer trucks
  • Timing devices
  • Office equipment
  • Test instruments
  • Medical/dental equipment
  • HVAC equipment
  • Manually operated devices
  • Valves

Search Keywords: DT2RS1A7

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
DT-2RS1-A7
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509055
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Straight Plunger
Contact Rating @ Voltage:
10@250VAC A
Maximum Movement Differential:
1.52 mm
Operating Force:
5.56 N
Termination Style:
Screw
Dimension:
49.3 x 17.5 x 44.9 mm
Body Orientation:
Straight
IP Rating:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 352

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$181.26
4
$165.81
8
$158.98
16
$157.40
200
$156.62
300 +
$155.84
