V3L-389 by honeywell
Image is representational - see manufacturer specifications
Honeywell Authorized Distributor

V3L-389

MICRO SWITCH™ Miniature Basic Switches: V3 Series, Single Pole Double Throw (SPDT), 4A 125 Vac, 4 oz Maximum Operating Force, Corrosion Resistant Integrated Straight Lever, Short Solder Terminals ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Snap Action Switches are electromechanical switch devices that are used to open or close an electrical circuit. Snap Action Switches or micro switches are used in various engineering applications and are available with several switch configurations and actuator styles. .

V3L-389 Snap Action Switch from Honeywell comes with maximum pre-travel of 3.18mm. This Honeywell switch uses very little force or pressure to operate and are usually triggered by an external force.

Product Highlights:

  • It has a maximum DC voltage of 250 V
  • Steel lever actuator
  • Release force of 0.14 N
  • Solder lug screw mount

Search Keywords: V3L389

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V3L-389
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
85365000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Lever
Contact Rating @ Voltage:
248.57 A
Maximum Movement Differential:
1.27 mm
Operating Force:
1.11 N
Termination Style:
Solder
Dimension:
30.16 x 10.16 x 23.57 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 1,022

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
5
$16.16
10
$15.12
25
$14.22
50
$13.54
100
$13.25
250
$13.16
500 +
$13.13
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
