CX-411-P by panasonic / sunx
Image is representational - see mfr. specs

CX-411-P

PANASONIC / SUNX

Photoelectric Sensor Thru-beam Light ON/Dark ON PNP 10m ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

CX-411-P is a compact through-beam photoelectric sensor with amplifier built-in, designed for reliable object detection in industrial applications. It features a 10 m (32.808 ft) sensing range with a red LED emitter operating at 680 nm peak emission wavelength, and provides PNP output with automatic interference prevention function. The sensor operates on 12 to 24 V DC supply with current consumption of 15 mA or less for the emitter and 10 mA or less for the receiver, delivering response times of 1 ms or less. With IP67 protection rating, operating temperature range of -25°C to +55°C, and hysteresis of 0.5 mm or less, the CX-411-P is well-suited for detecting small objects (ø12 mm or more) in dusty or challenging environments, offering stable detection with green LED indicators for power and operation status.

Search Keywords: CX411P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
PANASONIC / SUNX
Part No:
CX-411-P
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650900
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Thru-beam
Maximum Sensing Distance:
10 m
Output Type:
PNP
Maximum Response time:
1 ms
Minimum Operating Supply Voltage:
12 VDC
Maximum Operating Supply Voltage:
24 VDC
Operating Temperature:
-25 to 55 °C
Terminal Type:
Wire Lead
Dimension:
33.5 x 20 x 11.2 mm
Mounting:
N/A

IN STOCK: 9

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$102.04
5
$96.83
10
$95.88
20
$95.65
50
$95.41
100 +
$95.17
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

CN-24A-C2

Cable Assembly 2m M8 Circular SKT

CN-24AL-C2

M8 elbow Connector w/ 2m cablefor all CX-400 series

CN-24-C2

CN-22-C2

MS-CX-3

Sensor head - mounting bracket

MS-RF22

OS-CX-05

Long Sensing Range,Thru-Beam Type Compact Photoelectric Sensor

OS-CX-1X6

SLIT MASK 1MM X 6MM RECT FOR CX | Panasonic Industrial Automation OS-CX-1X6

Show 6 More
