V7-3E17D8 by honeywell

V7-3E17D8

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 10 A 125, 250, or 277 Vac, Pin Plunger, 50 g [1.76 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 4,75 mm x 0,51 mm [0.187 in x 0.02 in] Quick Connect Termination, UL, CSA ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. They are generally used in HVAC equipment, appliances, vending machines, manually operated devices, valves and gaming equipment, communications equipment, etc.

V7-3E17D8 Snap Action Switch from Honeywell has world-wide package size acceptance and a mechanical life of 10M. The Honeywell Switch is designed for 100K operations at a full load and is ideal for higher cost-of-failure applications.

Product Highlights:

  • Designed for 100K operations at a full load or 10M for mechanical life
  • This Honeywell Snap Action Switch has world-wide package size acceptance
  • Current rating of the Honeywell Switch ranges from 0.1 A to 25 A
  • It has UL/CSA and ENEC approvals
  • Best suited for higher cost-of-failure applications

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V73E17D8

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-3E17D8
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Pin Plunger
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.25 mm
Operating Force:
0.49 N
Termination Style:
Quick Connect
Dimension:
38.99 x 10.16 x 23.72 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 394

Ships today, if you order in

Minimum Order: 45

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
45
$4.380
50
$2.817
200 +
$2.771
