V7-3E19E9-263 by honeywell

V7-3E19E9-263

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 10 A 125, 250, or 277 Vac, ENEC 5 A 250 Vac, Additional ENEC Coverage @ 2 A Inductive 250 Vac, 32,8 mm [1.29 in] Simulated Roller Lever, 33 g [1.16 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA, ENEC ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part V7-3E19E9-263 is a MICRO SWITCH™ Miniature Basic Switch from the V7 Series. It features a Single Pole Double Throw (SPDT) configuration with a rating of 10 A 125, 250, or 277 Vac and an additional ENEC coverage of 5 A 250 Vac @ 2 A inductive. The switch comes with a 32.8 mm (1.29 in) simulated roller lever and has a maximum operating force of 33 g (1.16 oz). It also has 2.9 mm (0.11 in) mounting holes and can operate within a temperature range of -40 °C to 85 °C (-40 °F to 185 °F).The switch is designed with a 6.35 mm x 0.81 mm (0.250 in x 0.032 in) quick connect spread termination and is certified by UL, CSA, and ENEC for reliability and quality assurance.

Potential Applications:

  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches

Search Keywords: V73E19E9263

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-3E19E9-263
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Simulated Roller Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.76 mm
Operating Force:
0.32 N
Termination Style:
Quick Connect
Dimension:
50.04 x 10.16 x 28.93 mm
Body Orientation:
Straight
IP Rating:
N/A

IN STOCK: 2,950

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 10 Weeks

Price (CAD)

Qty
Unit Price
5
$10.014
50
$6.156
200
$5.267
400
$4.961
600
$4.931
1,000
$4.900
2,600
$4.869
5,000 +
$4.839
