22AC2-UL by honeywell

22AC2-UL

Honeywell

MICRO SWITCH™ Door Switches: AC Series, Single Pole Double Throw (SPDT), 15.1 A 125/250 Vac, 3 Position (Push-Momentary, Pull-Maintained), 4-40 UNC Threaded High Strength Thermoplastic Rod Actuator, Supplied with V3 Basic Switch, Round Head Termination Screws with Lockwashers, UL, CSA ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HONEYWELL part 22AC2-UL is a high-quality MICRO SWITCHâ„¢ door switch. It features a single pole double throw (SPDT) design and can handle up to 15.1 amps at 125/250 volts AC. The switch has a 3-position functionality, with a push-momentary and pull-maintained action. Constructed with a high-strength thermoplastic rod actuator, this switch is built to withstand tough conditions. It is supplied with a V3 basic switch, ensuring reliable and consistent performance. The switch also features round head termination screws with lockwashers for easy installation and secure connections.The 22AC2-UL door switch is UL and CSA certified, ensuring it meets the highest safety standards. It is a versatile and reliable solution for a variety of applications, offering durable performance and peace of mind.

Product Highlights:

  • Automatically cuts power when service door or drawer is opened
  • Choice of momentary, maintained or pull-to-cheat actuation
  • Versatile mounting bracket for side or end mounting
  • Current rating ranges from 5 A to 25 A
  • Available with one or two SPDT switches
  • UL recognized versions available
  • Choice of termination

Potential Applications:

  • Appliances
  • Vending machines
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment

Search Keywords: 22AC2UL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
22AC2-UL
RoHS:
Yes
HTS:
85365030
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Box
Type:
Door Interlock
Actuator Style:
Rod
Pole Throw Configuration:
SPDT
Maximum Current Rating:
15.1@250VAC A
Terminal Type:
Screw
Operating Temperature:
-18 to 82 °C
IP Rating:
N/A
Dimension:
60.33 x 13.21 x 41.53 mm
Switch Configuration:
N.O./N.C.
Body Orientation:
Straight

IN STOCK: 0

On Order: 80   can ship 12/15/25

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
1
$62.665
5
$60.070
10
$55.795
25
$53.426
50
$53.097
100
$52.829
250 +
$52.540
