HW1P-5Q4-G by idec corporation
Image is representational - see manufacturer specifications
IDEC Corporation Authorized Distributor

HW1P-5Q4-G

LED Lamp ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The HW1P-5Q4-G is a Ø22 mm jumbo dome pilot light designed for industrial control panels and equipment requiring clear visual indication from a distance and from the side. This LED-based unit operates at 24V AC/DC (±10%) with a rated current of 15 mA and features a polycarbonate lens available in multiple colors (amber, green, red, blue, white, yellow). The device is rated for -25 to +55°C operating temperature, -40 to +80°C storage temperature, and maintains 45 to 85% RH operating humidity with IP65 degree of protection. It delivers approximately 20,000 hours of LED lamp life (with luminance reducing to 50% on complete DC operation), features M3.5 screw terminals, and meets UL508, CSA C22.2 No. 14, and EN60947-1/5-1 safety standards. The pilot light is ideal for muting status indication, safety equipment monitoring, and general-purpose visual signaling in industrial automation and control systems.

Search Keywords: HW1P5Q4G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
HW1P-5Q4-G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Voltage Rating:
24 VAC
Color:
Green
Current Rating:
0.015 A
Lead/Base Style:
N/A
Lamp Size:
N/A

IN STOCK: 6

Ships today, if you order in

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$76.59
5
$73.56
10
$64.05
25
$63.88
50
$63.73
100
$55.94
250 +
$55.81
