RJ2S-C-D24 by idec corporation

RJ2S-C-D24

IDEC Corporation

Electromechanical Relay 24VDC 1.08KOhm 8A DPDT(28.8x12.7x33)mm Socket General Purpose Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

IDEC part RJ2S-C-D24 is an electromechanical relay designed for general purpose applications. With a coil voltage rating of 24VDC, this relay offers reliable switching capabilities for various electronic circuits. It features a double pole double throw (DPDT) configuration, allowing it to control two separate circuits simultaneously. The relay has a contact resistance of 1.08KOhm and can handle currents up to 8A. Its compact dimensions of 28.8x12.7x33mm make it suitable for space-constrained environments. The relay can be easily integrated into a circuit using a compatible socket. Trustworthy and durable, the IDEC RJ2S-C-D24 relay is an ideal choice for a wide range of industrial, commercial, and household applications.

Search Keywords: RJ2SCD24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
RJ2S-C-D24
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
8 A
Mounting:
Socket
Termination Style:
0.187Quick Connect & PC P in
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
1.08 KOhm

IN STOCK: 84

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
5
$8.575
50
$7.289
100
$6.616
250
$6.217
500
$6.171
1,000
$6.140
2,500
$6.110
5,000 +
$6.079
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Accessories

SJ2S-05BW

Conn Relay Socket SKT 8 POS Screw ST Panel Mount

SJ2S-07LW

Sockets Which Is Finger-safe DIN Rail Mount For RJ2S (Std)/RJ22S Series Slim Power Relays

SJ2S-61

Relay Socket for Electromechanical Relay

SJ9Z-JF2

2 Pole Jumpers for SJ Sockets

SJ9Z-JF5

BNDN1000

DIN Rail, 35mm, 1m Long

SJ9Z-JF8

8 Pole Jumpers for SJ Sockets

SJ9Z-JF10

Conn Jumper 10 POS ST

SJ9Z-PWPN10
