RU4S-C-A220 by idec corporation
Image is representational - see manufacturer specifications
IDEC Corporation Authorized Distributor

RU4S-C-A220

Electromechanical Relay 220/240VAC 18.23KOhm 6A 4PDT(27.5x21x41.6)mm Socket General Purpose Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The RU4S-C-A220 is a universal miniature 4-pole double-throw (4PDT) relay designed for general-purpose switching with a 220-240V AC coil. It features a maximum contact rating of 6A per pole and operates with a coil current of 4.2–5.0 mA at 50 Hz (3.6–4.2 mA at 60 Hz) with a coil resistance of 18,230 O at 20°C. The relay exhibits a pickup voltage of 80% maximum and a dropout voltage of 30% minimum, with a maximum continuous applied voltage of 110%. This relay includes a non-polarized green LED indicator, mechanical flag indicator for contact position confirmation, and a manual latching lever with color coding. It is lead-free, cadmium-free, and features no internal wires, making it environmentally compliant. The RU4S-C-A220 is UL Recognized, CSA Certified, and EN61810-1 compliant, making it suitable for industrial control, signaling, and switching applications where reliable miniature relay performance is required.

Search Keywords: RU4SCA220

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
IDEC Corporation
Part No:
RU4S-C-A220
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
220,240 V
DC Coil Voltage:
N/A
Contact Arrangement:
4PDT
Maximum Current Rating:
6 A
Mounting:
Socket
Termination Style:
Solder
Push to Test Button:
No
Led Indicator:
Yes
Operating Temperature:
-55 to 60 °C
Coil Resistance:
18.23 KOhm

IN STOCK: 79

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$15.81
25
$14.48
50
$13.44
100
$12.59
250
$12.04
500
$11.70
1,000 +
$11.67
